Rich Text Editor - Complete Guide

Lokus features a powerful rich text editor built on TipTap 3.4, providing an intuitive writing experience for both technical and non-technical users. The editor seamlessly combines the simplicity of Markdown with the power of a modern WYSIWYG editor, supporting everything from basic text formatting to advanced features like math equations, code syntax highlighting, and interactive components.

Version: 1.3.3 | Status: Production Ready | Extensions: 25+ | TipTap: 3.4 | Built with: React

Why This Editor?

• Zero Learning Curve: Write in Markdown or use visual formatting - your choice
• Blazing Fast: Optimized for documents with 10,000+ lines
• Extensible: Plugin API for custom extensions and slash commands
• Universal: Supports 100+ programming languages out of the box
• Scientific: Full LaTeX/KaTeX math equation support
• Connected: Wiki-style linking with autocomplete
• Smart: Intelligent paste detection and format conversion

What’s New in v1.3.3

Editor Enhancements

• Enhanced Smart Paste - Better HTML → Markdown conversion, preserves formatting
• Improved Autocomplete - Faster WikiLinks and tag suggestions with fuzzy matching
• 100+ Languages - Syntax highlighting for all major programming languages
• Enhanced Tables - Column resize, better cell editing, Excel paste support
• Split Pane Editing - Work on two notes simultaneously with Cmd/Ctrl + \
• Markdown Customization - Customize WikiLink styles, heading sizes, code themes
• Image Improvements - Better paste handling, auto-compression, lazy loading
• Performance - 40% faster initial load, smooth scrolling for large documents

Plugin System Integration

• Plugin API - Extend editor with custom extensions and commands
• Editor Extension Points - Plugins can register custom TipTap extensions
• Command Registration - Add custom slash commands via plugins
• Content Providers - Plugins can provide content and snippets
• Editor Event Hooks - Subscribe to editor events from plugins
• Hot Reloading - Live plugin updates during development

Keyboard Shortcuts

Master the editor with these keyboard shortcuts for maximum productivity.

Text Formatting Shortcuts

Document Structure Shortcuts

Code and Technical Shortcuts

Folding and Navigation

Editor Control Shortcuts

Text Formatting

Basic Formatting

The editor supports standard text formatting with both keyboard shortcuts and markdown syntax:

Bold Text: Make text stand out with bold formatting. Type **text** or use Cmd/Ctrl + B.

Italic Text: Emphasize text with italics. Type *text* or use Cmd/Ctrl + I.

Strikethrough: Cross out text for deletions. Type ~~text~~ or use Cmd/Ctrl + Shift + S.

Inline Code: Highlight code snippets inline. Type `code` or use Cmd/Ctrl + E.

==Highlight==: Highlight important text. Type ==text== or use Cmd/Ctrl + Shift + H.

Underline: Underline text. Use Cmd/Ctrl + U (no markdown equivalent).

Advanced Formatting

Superscript and Subscript: Perfect for mathematical and chemical formulas.

• Superscript: Type x^2^ to get x^2^
• Subscript: Type H~2~O to get H2O

Combining Formats: You can combine multiple formats:

• Bold and Italic: ***text***
• Bold Strikethrough: **~~text~~**
• **Code Bold**: `**text**`

Headers and Structure

The editor supports six levels of headers with automatic styling. Features include:

• Automatic table of contents generation
• Collapsible sections (see Folding Sections)
• Anchor links for deep linking
• Header numbering (optional)
• Custom header IDs

Example:

# Main Chapter (H1)
## Section Overview (H2)
### Subsection Details (H3)
#### Technical Notes (H4)
##### Additional Context (H5)
###### Fine Print (H6)

Lists and Organization

Task Lists

Create interactive checkboxes with full task management:

• Click to toggle completion
• Task statistics display
• Due date integration
• Priority markers
• Subtask support

Syntax:

- [ ] Incomplete task
- [x] Completed task
- [ ] Another task
  - [ ] Subtask indented

Ordered and Unordered Lists

Features:

• Auto-continuation on Enter
• Smart indentation with Tab/Shift+Tab
• Drag-and-drop reordering (coming soon)
• Multiple numbering styles
• Nested lists support

Unordered Lists:

- First item
- Second item
  - Nested item
  - Another nested
- Third item

Ordered Lists:

1. First step
2. Second step
   1. Sub-step A
   2. Sub-step B
3. Third step

Code Blocks

The editor supports 100+ programming languages with syntax highlighting powered by Highlight.js and Lowlight (a ProseMirror-compatible syntax highlighter). Code blocks in Lokus are designed for developers who need professional-grade code editing within their notes.

Creating Code Blocks

Method 1: Markdown Syntax (Recommended)

Type three backticks followed by the language identifier:

```javascript
function fibonacci(n) {
  if (n <= 1) return n;
  return fibonacci(n - 1) + fibonacci(n - 2);
}

The language identifier is **case-insensitive** and supports common aliases (e.g., `js`, `javascript`, `py`, `python`).

**Method 2: Keyboard Shortcut**

Press **Cmd/Ctrl + Alt + C** to instantly create a code block at your cursor position.

**Method 3: Slash Command**

Type `/code block` in the editor to open the slash command menu, then select "Code Block" to insert one.

### Supported Languages (100+)

The editor includes first-class syntax highlighting for over 100 programming languages. Here's a comprehensive list:

**Web Development:**
- **JavaScript** (js, javascript) - Full ES2024+ support
- **TypeScript** (ts, typescript) - Types, interfaces, decorators
- **HTML** (html, xml) - HTML5 with modern tags
- **CSS** (css) - CSS3, flexbox, grid
- **JSON** (json) - Syntax validation
- **YAML** (yaml, yml) - Config files
- **SCSS/SASS** (scss, sass) - CSS preprocessors
- **Vue** (vue) - Vue.js single-file components
- **JSX/TSX** - React components

**Backend Languages:**
- **Python** (py, python) - Python 3.x syntax
- **Java** (java) - Java 8+ features
- **C** (c) - ANSI C and C99/C11
- **C++** (cpp, c++, cxx) - C++11/14/17/20
- **C#** (csharp, cs) - .NET and Unity
- **Go** (go, golang) - Go 1.x syntax
- **Rust** (rust, rs) - Rust 2021 edition
- **PHP** (php) - PHP 7.x and 8.x
- **Ruby** (ruby, rb) - Ruby 3.x
- **Swift** (swift) - Swift 5.x
- **Kotlin** (kotlin, kt) - Kotlin for Android/JVM
- **Scala** (scala) - Functional programming
- **Perl** (perl, pl) - Perl 5 and 6
- **R** (r) - Statistical computing
- **Dart** (dart) - Flutter development

**Shell and Scripting:**
- **Bash** (bash, sh, shell) - Shell scripts
- **PowerShell** (powershell, ps1) - Windows automation
- **Batch** (batch, bat, cmd) - DOS scripts
- **Zsh** (zsh) - Z shell scripts
- **Fish** (fish) - Friendly shell

**Database and Query:**
- **SQL** (sql) - ANSI SQL
- **MySQL** (mysql) - MySQL-specific syntax
- **PostgreSQL** (postgresql, pgsql) - PostgreSQL features
- **GraphQL** (graphql, gql) - GraphQL schemas
- **MongoDB** (mongodb) - MongoDB queries

**Data and Config:**
- **Markdown** (markdown, md) - Markdown documents
- **TOML** (toml) - Tom's Obvious Minimal Language
- **INI** (ini) - Configuration files
- **Properties** (properties) - Java properties
- **Protobuf** (protobuf, proto) - Protocol buffers
- **XML** (xml) - XML documents

**Mobile Development:**
- **Objective-C** (objectivec, objc) - iOS legacy
- **Swift** (swift) - iOS modern
- **Kotlin** (kotlin) - Android modern
- **Java** (java) - Android legacy
- **Dart** (dart) - Flutter

**Systems and Low-Level:**
- **Assembly** (asm, assembly, x86) - Assembly language
- **LLVM** (llvm) - LLVM IR
- **WebAssembly** (wasm, wat) - WASM text format

**Functional Programming:**
- **Haskell** (haskell, hs) - Pure functional
- **Erlang** (erlang, erl) - Concurrent programming
- **Elixir** (elixir, ex) - Functional, concurrent
- **OCaml** (ocaml, ml) - Functional with objects
- **F#** (fsharp, fs) - .NET functional
- **Clojure** (clojure, clj) - Lisp dialect
- **Scheme** (scheme) - Lisp dialect
- **Lisp** (lisp) - Common Lisp

**Specialized Languages:**
- **LaTeX** (latex, tex) - Document typesetting
- **Vim** (vim) - Vimscript
- **Lua** (lua) - Scripting language
- **Arduino** (arduino, ino) - Arduino sketches
- **Dockerfile** (dockerfile, docker) - Docker configs
- **Nginx** (nginx) - Nginx configs
- **Apache** (apache) - Apache configs
- **Makefile** (makefile, make) - Build automation

### Code Block Features

Lokus's code blocks are built with the **CustomCodeBlock** extension, which extends TipTap's CodeBlockLowlight to provide a developer-friendly experience.

**Line Numbers**: Automatically displayed for easier reference and debugging.

**Syntax Highlighting**: Real-time syntax highlighting powered by Highlight.js with over 180 color tokens for precise code coloring.

**Language Detection**: Specify the language after the opening triple backticks:

```python
def fibonacci(n):
    """Calculate the nth Fibonacci number recursively."""
    if n <= 1:
        return n
    return fibonacci(n-1) + fibonacci(n-2)

# Example usage
print([fibonacci(i) for i in range(10)])
# Output: [0, 1, 1, 2, 3, 5, 8, 13, 21, 34]

Copy Code Button: One-click copying of entire code snippets to clipboard (coming soon).

No Auto-Exit Behavior: Unlike many editors, pressing Enter inside a code block inserts a newline rather than exiting the block. This prevents accidental exits while writing multi-line code.

Tab Support: Full tab indentation support within code blocks:

• Press Tab to indent (inserts actual tab character)
• Press Shift+Tab to unindent
• Press Enter to create a new line with smart indentation
• Tab key never loses editor focus

Smart Indentation: The CodeBlockIndent extension provides intelligent indentation:

• Automatically matches indentation of previous line
• Preserves tab characters (doesn’t convert to spaces)
• Works seamlessly with all programming languages

Escape Mechanism: To exit a code block:

1. Position cursor at the start of an empty line
2. Press Backspace to convert the code block to a normal paragraph
3. Alternative: Use arrow keys to navigate out

Code Block Keyboard Shortcuts

Code Block Tips and Tricks

1. Quick Language Switch: Click on the language identifier at the top of the code block to change it (or edit directly in source mode)

2. Paste Code Intelligently: The editor automatically detects code from your clipboard and:

   • Preserves indentation and formatting
   • Creates a code block automatically if pasting multi-line code
   • Detects the programming language from syntax patterns

3. Escape Code Block: Position cursor at the beginning of an empty line and press Backspace to exit

4. Multi-line Selection: Select multiple lines of text and press Cmd/Ctrl + Alt + C to convert them all into a code block

5. Language Aliases: Use common abbreviations:

   • js or javascript
   • py or python
   • ts or typescript
   • cpp or c++
   • All are case-insensitive

6. Performance: Code blocks with 1000+ lines of code are optimized for smooth scrolling and editing

Real-World Code Examples

JavaScript/TypeScript:

interface User {
  id: number;
  name: string;
  email: string;
}

async function fetchUser(id: number): Promise<User> {
  const response = await fetch(`/api/users/${id}`);
  if (!response.ok) {
    throw new Error('Failed to fetch user');
  }
  return response.json();
}

Python with Type Hints:

from typing import List, Optional

class TreeNode:
    def __init__(self, val: int = 0, left: Optional['TreeNode'] = None,
                 right: Optional['TreeNode'] = None):
        self.val = val
        self.left = left
        self.right = right

def inorder_traversal(root: Optional[TreeNode]) -> List[int]:
    """Perform inorder traversal of binary tree."""
    result = []

    def traverse(node: Optional[TreeNode]) -> None:
        if not node:
            return
        traverse(node.left)
        result.append(node.val)
        traverse(node.right)

    traverse(root)
    return result

Rust:

use std::collections::HashMap;

fn word_frequency(text: &str) -> HashMap<String, usize> {
    let mut frequencies = HashMap::new();

    for word in text.split_whitespace() {
        let word = word.to_lowercase();
        *frequencies.entry(word).or_insert(0) += 1;
    }

    frequencies
}

fn main() {
    let text = "hello world hello rust";
    let freqs = word_frequency(text);
    println!("{:?}", freqs);
}

Go:

package main

import (
    "fmt"
    "sync"
)

func worker(id int, jobs <-chan int, results chan<- int, wg *sync.WaitGroup) {
    defer wg.Done()
    for job := range jobs {
        fmt.Printf("Worker %d processing job %d\n", id, job)
        results <- job * 2
    }
}

func main() {
    jobs := make(chan int, 100)
    results := make(chan int, 100)

    var wg sync.WaitGroup
    for w := 1; w <= 3; w++ {
        wg.Add(1)
        go worker(w, jobs, results, &wg)
    }

    for j := 1; j <= 9; j++ {
        jobs <- j
    }
    close(jobs)

    wg.Wait()
    close(results)
}

Math Equations

Lokus uses KaTeX 0.16+ for beautiful mathematical typesetting with full LaTeX syntax support.

Inline Math

Inline math equations flow with your text. Type a LaTeX expression between single dollar signs:

The famous equation $E=mc^2$ was discovered by Einstein.

Result: The famous equation $E=mc^2$ was discovered by Einstein.

More Examples:

• Pythagorean theorem: $a^2 + b^2 = c^2$
• Quadratic formula: $x = \frac{-b \pm \sqrt{b^2-4ac}}{2a}$
• Greek letters: $\alpha, \beta, \gamma, \Delta, \Omega$
• Integrals: $\int_0^1 x^2 dx$

Block Math

Block math equations are displayed on their own line with centered alignment. Type a LaTeX expression between double dollar signs:

$$
\int_{-\infty}^{\infty} e^{-x^2} dx = \sqrt{\pi}
$$

Result: Centered, larger equation perfect for important formulas.

Complex Examples:

Maxwell’s Equations:

$$
\begin{aligned}
\nabla \cdot \mathbf{E} &= \frac{\rho}{\epsilon_0} \\
\nabla \cdot \mathbf{B} &= 0 \\
\nabla \times \mathbf{E} &= -\frac{\partial \mathbf{B}}{\partial t} \\
\nabla \times \mathbf{B} &= \mu_0\mathbf{J} + \mu_0\epsilon_0\frac{\partial \mathbf{E}}{\partial t}
\end{aligned}
$$

Matrix Notation:

$$
\begin{bmatrix}
a & b \\
c & d
\end{bmatrix}
\begin{bmatrix}
x \\
y
\end{bmatrix}
=
\begin{bmatrix}
ax + by \\
cx + dy
\end{bmatrix}
$$

Math Features

KaTeX Integration: Fast, server-side rendering of LaTeX math formulas.

Error Handling: Invalid LaTeX syntax is highlighted in red with helpful error messages instead of breaking the editor.

Custom Macros: Define your own LaTeX macros for frequently used notation.

Auto-sizing Delimiters: Brackets, parentheses, and braces automatically resize to fit their content.

Copy LaTeX Source: Click on any rendered equation to edit or copy its LaTeX source.

Supported LaTeX Commands

Basic Operations:

• Fractions: \frac{numerator}{denominator}
• Exponents: x^2, x^{2+3}
• Subscripts: x_1, x_{i,j}
• Roots: \sqrt{x}, \sqrt[n]{x}

Greek Letters:

• Lowercase: \alpha, \beta, \gamma, \delta, \epsilon, \theta, \lambda, \mu, \pi, \sigma, \omega
• Uppercase: \Gamma, \Delta, \Theta, \Lambda, \Sigma, \Omega

Operators:

• Summation: \sum_{i=1}^{n}
• Product: \prod_{i=1}^{n}
• Integrals: \int, \iint, \iiint, \oint
• Limits: \lim_{x \to \infty}

Relations:

• \leq, \geq, \neq, \approx, \equiv, \sim, \propto
• \subset, \subseteq, \in, \notin

Functions:

• \sin, \cos, \tan, \log, \ln, \exp, \max, \min

Math Tips and Tricks

1. Preview While Typing: Math equations render in real-time as you type
2. Common Mistakes: Remember to escape special characters with backslash
3. Alignment: Use \begin{aligned} for multi-line equations with alignment
4. Spacing: Use \, for thin space, \: for medium space, \; for thick space
5. Text in Math: Use \text{your text} to include regular text in equations

Tables

Create structured data with markdown tables featuring:

• Column alignment (left, center, right)
• Resizable columns
• Sortable columns
• Row/column insertion
• Cell merging
• CSV import/export
• Excel paste support

Basic Table Syntax:

| Header 1 | Header 2 | Header 3 |
|----------|----------|----------|
| Cell 1   | Cell 2   | Cell 3   |
| Cell 4   | Cell 5   | Cell 6   |

Column Alignment:

| Left Align | Center Align | Right Align |
|:-----------|:------------:|------------:|
| Left       | Center       | Right       |

Creating Tables:

• Type /table for slash command with size picker
• Paste from Excel/Google Sheets (auto-converts)
• Keyboard shortcut: Insert via context menu

Images and Media

Image Features

• Drag-and-drop upload
• Paste from clipboard
• Resize handles
• Alignment options
• Captions
• Lightbox view
• Lazy loading
• Image optimization

Image Syntax:

![Alt text](image-url.jpg)
![Logo](https://example.com/logo.png)

Image Commands:

• Type /image for slash command
• Paste images directly from clipboard
• Use image picker modal

Videos and Audio

Support for embedding video and audio files (coming soon).

Links

Standard Links

Create hyperlinks with markdown syntax:

[Link Text](https://example.com)
[Documentation](/docs/guide)

Auto-linking

URLs and email addresses are automatically converted to links:

• https://example.com → Clickable link
• user@example.com → Mailto link

Wiki Links

See Wiki Links for internal linking with [[double brackets]].

Smart Features

Smart Paste

The Smart Paste feature intelligently processes content from your clipboard, preserving formatting and converting to appropriate markdown structures.

Web Content: When you paste from web pages, the editor:

• Converts HTML to clean markdown
• Preserves text formatting (bold, italic, links)
• Maintains list structure and hierarchy
• Extracts images with proper alt text
• Cleans up unnecessary styling

Code Detection: Paste code from any editor and Lokus will:

• Detect the programming language automatically
• Preserve indentation and formatting
• Create proper code blocks with syntax highlighting
• Handle multi-line code snippets

Spreadsheet Data: Paste from Excel or Google Sheets:

• Automatically converts to markdown tables
• Preserves column structure
• Handles merged cells intelligently
• Maintains data formatting

Markdown Content: When pasting markdown:

• Recognizes markdown syntax patterns
• Converts to rich text format
• Preserves wiki links: [[Link]]
• Handles math equations: $x^2$ and $$E=mc^2$$
• Maintains code blocks with language tags

How It Works:

The MarkdownPaste extension uses a universal markdown compiler to detect and convert markdown patterns:

// Detection logic
const compiler = getMarkdownCompiler();
if (compiler.isMarkdown(text)) {
  const htmlContent = compiler.compile(text);
  editor.insertContent(htmlContent);
}

Auto-completion

Context-aware suggestions appear as you type, helping you work faster and maintain consistency.

Wiki Links Autocomplete: Type [[ to trigger file suggestions:

• Shows all files in your workspace
• Fuzzy search by filename
• Displays file paths for disambiguation
• Supports # for heading anchors
• Handles | for custom link text

Example: [[my-note#section|Custom Text]]

Tag Autocomplete: Type # to see tag suggestions:

• Shows existing tags from your notes
• Fuzzy matching on tag names
• Most popular tags shown first
• Creates new tags on the fly
• Doesn’t trigger inside code blocks

Example: #project #important #meeting-notes

Smart Behavior:

• Autocomplete respects context (won’t trigger in code blocks)
• Arrow keys to navigate suggestions
• Enter to select
• Esc to dismiss
• Continues typing to filter results

Smart Formatting

The editor automatically converts certain patterns into formatted content:

Typography:

• (c) → ©
• (r) → ®
• (tm) → ™
• 1/2 → ½
• -> → →
• <- → ←

Smart Lists:

• Auto-continue lists on Enter
• Outdent with Shift+Tab
• Indent with Tab
• Convert - [ ] to task items
• Number lists automatically

Smart Quotes (optional):

• "text" → “text”
• 'text' → ‘text’

URL Detection:

• Automatically converts URLs to links
• Email addresses become mailto: links
• No need to use markdown link syntax

Slash Commands

The slash command menu provides quick access to all editor features. Type / anywhere in the editor to open the command palette.

Tasks & Kanban

Basic Blocks

Formatting

Code

Math

Using Slash Commands

1. Type / to open the command palette
2. Start typing to filter commands (e.g., /tab shows table command)
3. Use arrow keys to navigate
4. Press Enter to execute
5. Press Esc to dismiss

Pro Tips:

• Slash commands work anywhere in the document
• Partial matching: /h1 finds “Heading 1”
• Commands are organized by category
• Recently used commands appear first

Callouts and Admonitions

Create visually distinct blocks for notes, warnings, tips, and more using callout syntax.

Syntax

>[!type] Optional Title
Content goes here

Callout Types

Note - General information:

>[!note] Remember
This is important information to keep in mind.

Tip - Helpful suggestions:

>[!tip] Pro Tip
Use keyboard shortcuts for faster editing!

Warning - Caution notices:

>[!warning] Be Careful
This operation cannot be undone.

Danger - Critical alerts:

>[!danger] Danger
This will delete all your data!

Info - Informational blocks:

>[!info] Did You Know?
Lokus supports 100+ programming languages.

Success - Success messages:

>[!success] Great Job!
Your changes have been saved.

Question - Questions or FAQs:

>[!question] How does this work?
Callouts use markdown blockquote syntax.

Example - Code or usage examples:

>[!example] Example
Here's how to use this feature...

Collapsible Callouts

Add a minus sign after the type to make callouts collapsible:

>[!note]- Click to Expand
This content is hidden by default.

Nested Content

Callouts support nested markdown:

• Lists
• Bold and italic text
• Code blocks
• Links and images
• Even other callouts!

Keyboard Shortcut

Press Cmd/Ctrl + Alt + C to create a callout.

Folding Sections

Organize long documents by folding heading sections to hide content.

How to Fold

Method 1: Click the Gutter

• Hover over any heading
• Click the arrow icon (▶/▼) in the left gutter
• The section collapses/expands

Method 2: Keyboard Shortcuts

• Cmd/Ctrl + Alt + [ - Fold current section
• Cmd/Ctrl + Alt + ] - Unfold current section
• Cmd/Ctrl + Alt + 0 - Unfold all sections

Folding Behavior

Hierarchical Folding: Folding a heading hides all content until the next heading of equal or higher level.

Example:

# Chapter 1 (fold this)
Content...
## Section 1.1
Content...
## Section 1.2
Content...
# Chapter 2 (folding stops here)

Persistent State: Fold states are saved per file in localStorage, so your folds persist across sessions.

Visual Indicators:

• ▼ = Expanded section
• ▶ = Collapsed section

Folding Tips

1. Navigate Large Documents: Fold sections you’re not working on
2. Focus Mode: Collapse everything except your current section
3. Outline View: Fold all to see document structure
4. Selective Expansion: Unfold only what you need

Split Pane Editing

Work on two notes simultaneously with split pane editing.

Activate Split Pane:

• Press *Cmd/Ctrl + * to split the editor horizontally
• Each pane has independent scrolling and cursor position
• Drag the divider to resize panes

Use Cases:

• Reference one note while writing another
• Compare two documents side-by-side
• Copy/paste between notes efficiently
• View different sections of the same long document

Editor Modes

Lokus offers three distinct editor modes to suit different workflows:

Edit Mode (Default)

The standard editing mode with full WYSIWYG editing capabilities. This is the mode you’ll use most of the time.

• Full editing: All formatting tools available
• Real-time rendering: Math equations, wiki links render instantly
• Smart features: Autocomplete, smart paste, slash commands all active
• Keyboard shortcuts: All shortcuts enabled

Use when: Writing, editing, formatting content

Live Preview Mode

A hybrid mode that shows both markdown syntax hints and rendered output simultaneously. Perfect for markdown purists who want visual feedback.

• Source hints: See markdown syntax (e.g., **bold**)
• Rendered output: See how it looks rendered
• Editing enabled: Full editing capabilities maintained
• Learning tool: Great for learning markdown syntax

Activate: Press Cmd/Ctrl + E to cycle to Live Preview mode

Use when: Learning markdown, debugging formatting issues, wanting to see source

Reading Mode

A distraction-free, non-editable view optimized for reading and reviewing content.

• No editing: Content is read-only
• Clean interface: Removes editing UI elements
• Optimized typography: Enhanced reading experience
• Full rendering: All content (math, images, tables) fully rendered

Activate: Press Cmd/Ctrl + E twice to cycle to Reading mode

Use when: Reviewing notes, presenting content, distraction-free reading

Mode Shortcuts

Pro Tip: Mode preference is saved per-file, so each note can have its own default mode.

TipTap Extensions Reference

Lokus uses 25+ TipTap extensions to power the editor. Here’s a comprehensive list of all extensions and their purposes:

Core Extensions (from StarterKit)

Document & Structure:

• Document - Root document node
• Paragraph - Standard paragraph blocks
• Text - Text content nodes
• Heading - Six levels of headings (H1-H6)
• HardBreak - Line breaks
• HorizontalRule - Horizontal dividers

Lists:

• BulletList - Unordered lists with bullets
• OrderedList - Numbered lists
• ListItem - List item containers
• TaskList - Interactive checkbox lists
• TaskItem - Individual task items with checkboxes

Formatting Marks:

• Bold - Bold text formatting
• Italic - Italic text emphasis
• Strike - Strikethrough text
• Code - Inline code formatting
• Highlight - Text highlighting with colors

Blocks:

• Blockquote - Quotation blocks
• CodeBlock - Multi-line code blocks (replaced by CustomCodeBlock)

History:

• History - Undo/redo functionality

Custom Lokus Extensions

Advanced Blocks:

• CustomCodeBlock - Enhanced code blocks with 100+ languages and smart indentation
• CodeBlockIndent - Tab support and smart indentation for code blocks
• Table - Full-featured tables with resizing
• TableRow, TableHeader, TableCell - Table components

Math & Science:

• MathInline - Inline LaTeX equations ($x^2$)
• MathBlock - Display LaTeX equations ($E=mc^2$)

Links & References:

• Link - Standard hyperlinks with auto-detection
• WikiLink - Internal wiki-style links [[page]]
• WikiLinkSuggest - Autocomplete for wiki links
• Image - Image embedding with resize

Typography:

• Superscript - Superscript text (x^2^)
• Subscript - Subscript text (H2O)

Smart Features:

• Placeholder - “Press ’/’ for commands…” hint
• SlashCommand - Slash command menu system
• MarkdownPaste - Smart paste with HTML→Markdown conversion
• MarkdownTablePaste - Excel/Google Sheets → Markdown tables
• TagAutocomplete - Hashtag suggestions with fuzzy search

Tasks & Kanban:

• SmartTask - Advanced task management (not in default build)
• SimpleTask - Standalone tasks with !task syntax
• TaskSyntaxHighlight - Visual highlighting for task syntax
• TaskMentionSuggest - @task autocomplete
• TaskCreationTrigger - Modal for creating tasks

Advanced UI:

• Callout - Admonition blocks with 8 types
• Folding - Collapsible heading sections

Configuration:

• HeadingAltInput - Alternative heading input markers (disabled)
• Template - Template variable substitution

Extension Configuration

Extensions can be configured via Settings → Editor → Extensions. Common configurations include:

CodeBlock Theme:

{
  languageClassPrefix: 'language-',
  defaultLanguage: 'plaintext',
  HTMLAttributes: { class: 'code-block' }
}

Link Behavior:

{
  openOnClick: false,  // Cmd+Click to follow links
  autolink: true,      // Auto-detect URLs
  linkOnPaste: true    // Convert pasted URLs to links
}

Image Settings:

{
  inline: true,
  allowBase64: true,
  HTMLAttributes: { class: 'editor-image' }
}

Creating Custom Extensions

Developers can create custom TipTap extensions using the Plugin API:

import { Extension } from '@tiptap/core';
import { editorAPI } from './plugins/api/EditorAPI';

const MyExtension = Extension.create({
  name: 'myExtension',

  addCommands() {
    return {
      myCommand: () => ({ commands }) => {
        commands.insertContent('Hello from my extension!');
        return true;
      }
    };
  },

  addKeyboardShortcuts() {
    return {
      'Mod-Shift-H': () => this.editor.commands.myCommand()
    };
  }
});

// Register with editor API
editorAPI.registerExtension(MyExtension);

See the Developer Guide for complete extension development documentation.

Plugin Integration

Lokus v1.3.3 introduces a comprehensive plugin system that allows developers to extend the editor with custom functionality, similar to VS Code’s extensibility model.

Editor Plugin Capabilities

Custom Extensions: Plugins can register custom TipTap extensions to add new editor features:

// Example: Custom extension via plugin
export function activate(context) {
  const customExtension = Extension.create({
    name: 'myCustomFeature',
    addCommands() {
      return {
        insertCustomBlock: () => ({ commands }) => {
          commands.insertContent('<div class="custom-block">Content</div>');
          return true;
        }
      };
    }
  });

  context.editor.registerExtension(customExtension);
}

Slash Command Registration: Add custom commands to the slash command menu:

context.editor.registerSlashCommand({
  title: 'Insert Custom Block',
  description: 'Adds a custom content block',
  command: 'myPlugin.insertCustomBlock',
  category: 'blocks'
});

Content Manipulation: Plugins can read, modify, and insert content:

// Get editor content
const content = context.editor.getContent();

// Insert text at cursor
context.editor.insertText('Custom text from plugin');

// Replace selection
context.editor.replaceSelection('New content');

// Access TipTap editor instance
const editor = context.editor.getInstance();

Event Subscriptions: Listen to editor events:

// Content changes
context.editor.onDidChangeContent((event) => {
  console.log('Content changed:', event);
});

// Selection changes
context.editor.onDidChangeSelection((selection) => {
  console.log('Selection:', selection);
});

// Document saved
context.editor.onDidSave((filePath) => {
  console.log('Document saved:', filePath);
});

Use Cases for Editor Plugins

Formatting Enhancements:

• Custom text transformations
• Advanced find and replace
• Batch formatting operations
• Template expansion

Content Generation:

• AI-powered writing assistance
• Code snippet insertion
• Boilerplate generation
• Dynamic content from APIs

Analysis Tools:

• Word count and readability
• Grammar and spell checking
• Citation management
• Content validation

Integration Features:

• External service integration
• Custom data providers
• Real-time collaboration features
• Version control integration

Security Considerations

All editor plugins run in a sandboxed environment with:

• Limited DOM access
• Permission-based API access
• Content Security Policy enforcement
• Resource usage monitoring

Plugins must declare editor:modify permission in their manifest to modify editor content.

Learn More

• Plugin System Overview - Complete plugin architecture
• Plugin Development Guide - Build your own plugins
• Plugin API Reference - Detailed API documentation
• Plugin Marketplace - Discover community plugins

Performance Optimization

Lokus is optimized for handling large documents with thousands of lines. Here’s what makes it fast:

Performance Features

Lazy Rendering:

• Only visible content is rendered initially
• Off-screen content loads as you scroll
• Improves initial load time by 40%

Debounced Saves:

• Auto-save triggered after 500ms of inactivity
• Prevents excessive file writes
• Configurable interval in Settings

Efficient Re-renders:

• shouldRerenderOnTransaction: false prevents unnecessary React re-renders
• Only changed nodes are updated in the DOM
• Selection changes don’t trigger full re-renders

Smart Decorations:

• Folded sections use ProseMirror decorations (no DOM manipulation)
• Syntax highlighting caches language parsers
• Math equations render once and cache

Optimized Plugins:

• WikiLink resolution is asynchronous
• Tag indexing happens in background
• File index is cached in memory

Performance Tips

1. Use Folding for Long Documents: Fold sections you’re not working on to improve scroll performance

2. Limit Real-time Features in Large Files: Disable autocomplete for files over 50,000 words

3. Optimize Images: Use optimized/compressed images rather than raw high-res files

4. Break Up Large Documents: Split very long documents (10,000+ lines) into separate notes

5. Close Unused Notes: The editor is fast, but keeping 20+ notes open will consume memory

6. Disable Unused Extensions: In Settings, disable extensions you don’t use

Performance Benchmarks

Tested on: MacBook Pro M1, 16GB RAM, macOS Sonoma

Troubleshooting Common Issues

Issue: Math equations not rendering

Symptoms: Equations show as $x^2$ instead of rendered math

Solution:

1. Check that KaTeX is loaded (open DevTools Console)
2. Verify LaTeX syntax is correct
3. Try refreshing the note
4. Check for JavaScript errors in console

Issue: Wiki links not resolving

Symptoms: Links show as [[page]] instead of hyperlinks

Solution:

1. Ensure the target file exists in the workspace
2. Check file index is built (Settings → Advanced → Rebuild Index)
3. Verify workspace path is set correctly
4. Try restarting Lokus

Issue: Code blocks not highlighting

Symptoms: Code appears as plain text without colors

Solution:

1. Specify language after backticks: ```python
2. Check if language is supported (see language list)
3. Verify code block theme is set (Settings → Editor → Theme)

Issue: Autocomplete not working

Symptoms: No suggestions appear when typing [[ or #

Solution:

1. Check autocomplete is enabled (Settings → Editor → Autocomplete)
2. Ensure you’re not in a code block (autocomplete disabled there)
3. Wait 100ms after typing trigger character
4. Check file index exists for wiki links

Issue: Performance lag with large documents

Symptoms: Slow typing, delayed cursor movement

Solution:

1. Enable section folding and fold unused sections
2. Disable real-time features (Settings → Performance)
3. Split document into smaller notes
4. Close other open notes
5. Restart Lokus to clear memory

Issue: Paste not working correctly

Symptoms: Pasted content appears unformatted or broken

Solution:

1. Try paste as plain text (Cmd/Ctrl + Shift + V)
2. Check if Smart Paste is enabled (Settings → Editor)
3. Report the issue with source content for investigation

Getting Help

If you encounter issues not covered here:

• Check the FAQ
• Search existing GitHub Issues
• Join the Discord Community
• File a Bug Report

Best Practices

Writing Tips

1. Use headers to structure content
2. Break up text with short paragraphs
3. Use lists to organize information
4. Add links to connect related notes
5. Use code blocks for technical content
6. Add images to enhance understanding

Markdown Style

• One blank line between sections
• Consistent list markers
• ATX headers (# not =)
• Fenced code blocks
• Reference-style links for readability

Advanced Tips and Workflows

Power User Shortcuts

These lesser-known shortcuts will supercharge your editing:

1. Multi-cursor Editing: Hold Alt and click to place multiple cursors (coming soon)
2. Select Line: Cmd/Ctrl + L to select entire current line (coming soon)
3. Duplicate Line: Cmd/Ctrl + Shift + D to duplicate current line (coming soon)
4. Move Line Up/Down: Alt + Up/Down to move lines (coming soon)
5. Delete Line: Cmd/Ctrl + Shift + K to delete current line (coming soon)

Workflow: Meeting Notes

Optimize for quick meeting note-taking:

# Meeting: Product Roadmap Q1 2025
**Date:** 2025-01-23 | **Attendees:** [[Alice]], [[Bob]], [[Charlie]]

## Agenda
- [ ] Review Q4 metrics
- [ ] Discuss Q1 priorities
- [ ] Budget approval

## Notes
- Q4 revenue exceeded targets by 15%
- Key priority: Mobile app launch

## Action Items
- [ ] !task Alice to finalize mobile designs by 2025-02-01
- [ ] !task Bob to prepare budget deck
- [ ] [[Follow-up meeting]] scheduled for 2025-02-15

Pro Tips:

• Use task lists for agenda items
• Link to attendees’ notes with wiki links
• Create tasks for action items
• Add dates and deadlines inline

Workflow: Technical Documentation

Best practices for documenting code:

# Authentication System Documentation

## Overview
Our authentication uses JWT tokens with refresh token rotation.

## Architecture
```mermaid
graph LR
    A[Client] --> B[API Gateway]
    B --> C[Auth Service]
    C --> D[User DB]

Implementation

Token Generation

interface TokenPair {
  accessToken: string;
  refreshToken: string;
  expiresIn: number;
}

async function generateTokens(userId: string): Promise<TokenPair> {
  const accessToken = jwt.sign({ userId }, SECRET, { expiresIn: '15m' });
  const refreshToken = await createRefreshToken(userId);
  return { accessToken, refreshToken, expiresIn: 900 };
}

Security Considerations

[!warning] Important Never store JWT secrets in code. Use environment variables.

[!tip] Best Practice Set access token expiry to 15 minutes for optimal security/UX balance.

API Reference

See [[API Documentation]] for complete endpoint details.

Related

• [[User Management System]]
• [[Security Guidelines]]
• [[API Rate Limiting]]

**Pro Tips:**
- Use callouts for warnings and tips
- Code examples with syntax highlighting
- Link to related documentation
- Include diagrams with Mermaid (if supported)

### Workflow: Academic Writing

Optimize for research and citations:

```markdown
# Literature Review: Machine Learning in Healthcare

## Abstract
This review examines recent applications of ML in healthcare diagnostics.

## Key Findings

### Computer Vision for Medical Imaging
Recent studies show CNNs achieve 95% accuracy in detecting pneumonia from
chest X-rays [[Smith et al. 2024]].

Mathematical formulation of CNN layers:
$$
y = \sigma(W \cdot x + b)
$$

where $\sigma$ is the activation function, $W$ the weight matrix, and $b$ the bias.

### Natural Language Processing
Transformer models show promise in analyzing clinical notes:
- **BERT**: Accuracy 87% on ICD-10 coding [[Jones 2024]]
- **GPT-4**: 92% on diagnostic reasoning [[Lee et al. 2024]]

## Methodology

### Data Collection
Sample size: $n = 10,000$ patients
Confidence interval: $95\%$
Margin of error: $\pm 3\%$

Statistical test:
$$
t = \frac{\bar{x} - \mu}{s / \sqrt{n}}
$$

## Citations
See [[References]] for complete bibliography.

#research #healthcare #machine-learning

Pro Tips:

• Use LaTeX for equations
• Tag notes for easy searching
• Link to reference notes
• Use tables for data comparison

Workflow: Project Planning

Structure for project management:

# Project: Mobile App Redesign

## Project Overview
**Status:** In Progress | **Due:** 2025-03-31 | **Owner:** [[Sarah]]

## Goals
- [ ] Improve user retention by 25%
- [ ] Reduce load time to `<2s`
- [ ] Achieve 4.5+ app store rating

## Timeline
```mermaid
gantt
    title Project Timeline
    section Design
    Wireframes: 2025-01-15, 2w
    Mockups: 2025-01-29, 2w
    section Development
    Frontend: 2025-02-12, 4w
    Backend: 2025-02-12, 4w

Kanban Board

!task Sprint 1 Tasks

• [[Design System]] - In Progress
• [[User Research]] - Done
• [[API Integration]] - Todo

Team

Resources

• [[Design Files]]
• [[Technical Spec]]
• [[API Documentation]]

#project #mobile-app

**Pro Tips:**
- Use tables for team assignments
- Link to related documents
- Track progress with task lists
- Tag for project filtering

## FAQ

### Can I use the editor offline?
Yes! Lokus works completely offline. All editing happens locally on your machine.

### Does the editor support Vim keybindings?
Vim mode is planned for a future release.

### How do I add custom keyboard shortcuts?
Use the Plugin API to create custom extensions with keyboard shortcuts. See [Developer Guide](/developers).

### Can I export notes to other formats?
Yes! Export to Markdown, HTML, and PDF. DOCX and LaTeX export coming soon.

### Does it support collaborative editing?
Not yet. Collaborative editing is planned for v2.0.

### What happens to my formatting when I export?
Markdown export preserves all syntax. HTML/PDF export renders formatting visually. LaTeX export converts to LaTeX syntax.

### Can I customize the editor theme?
Yes! Go to Settings → Appearance to customize colors, fonts, and themes. See [Themes](/features/themes).

### How do I backup my notes?
Notes are stored as plain markdown files. Simply backup your workspace folder. Cloud sync coming soon.

## Summary: Why Lokus Editor Stands Out

### Unique Features

**1. True Markdown + WYSIWYG Hybrid**
- Write in markdown OR use visual formatting
- No other editor balances both this well
- Switch between modes seamlessly

**2. 100+ Programming Languages**
- More language support than Notion, Obsidian, or Bear
- Professional-grade syntax highlighting
- Smart indentation and tab support

**3. Scientific Math Support**
- Full KaTeX/LaTeX integration
- Inline and block equations
- Real-time rendering

**4. Wiki-Style Linking**
- Obsidian-style `[[links]]`
- Autocomplete with fuzzy search
- Automatic file resolution

**5. Extensible Architecture**
- Plugin API for custom extensions
- Slash command registration
- Full TipTap ecosystem access

### Comparison with Other Editors

| Feature | Lokus | Notion | Obsidian | VS Code |
|---------|-------|--------|----------|---------|
| Markdown Native | Yes | Partial | Yes | Yes |
| Math Equations | Yes | Partial | Yes | Partial |
| Wiki Links | Yes | Partial | Yes | No |
| 100+ Languages | Yes | Partial | Partial | Yes |
| Offline First | Yes | No | Yes | Yes |
| Plugin API | Yes | No | Yes | Yes |
| Section Folding | Yes | Yes | Partial | Yes |
| Smart Paste | Yes | Yes | Partial | No |
| Callouts | Yes | Yes | Yes | No |
| Free & Open | Yes | No | Yes | Yes |

**Legend:** Yes = Full support | Partial = Partial support | No = Not supported

### Performance Metrics

- **Startup Time:** < 500ms for most documents
- **Keystroke Latency:** < 16ms (60 FPS)
- **Memory Usage:** ~150MB for typical workspace
- **File Size Limit:** Tested up to 50MB markdown files
- **Concurrent Notes:** Handles 50+ open notes smoothly

### The Bottom Line

Lokus's editor is built for **knowledge workers who need both speed and power**. Whether you're a developer documenting code, a researcher writing papers, a student taking notes, or a writer crafting content, Lokus provides the tools you need without getting in your way.

**Key Strengths:**
- **Fast**: Optimized for large documents
- **Flexible**: Markdown or WYSIWYG, your choice
- **Powerful**: 25+ extensions, 100+ languages
- **Extensible**: Plugin API for customization
- **Universal**: Works on Mac, Windows, Linux

**Start writing better notes today.** The editor is production-ready and actively maintained.

## Next Steps

Ready to become a Lokus power user?

- **Beginners**: Start with the [Quick Start Guide](/docs/quick-start)
- **Markdown Users**: Explore [Wiki Links](/features/wiki-links) for connecting notes
- **Developers**: Check out [Code Blocks & Syntax Highlighting](#code-blocks) above
- **Scientists**: Master [Math Equations](#math-equations) with LaTeX
- **Power Users**: Learn [Advanced Tips](#advanced-tips-and-workflows) and workflows
- **Customizers**: Read [Templates](/features/templates) for efficient note creation
- **Designers**: Check out [Themes](/features/themes) for customizing appearance
- **Developers**: See [Developer Guide](/developers) for creating extensions
- **Community**: Join the Discord to share tips

**Questions?** Check the [FAQ](#faq) or reach out on Discord.

---

**Last Updated:** November 12, 2025 | **Editor Version:** 1.3.3 | **TipTap Version:** 3.4

*This documentation is actively maintained. Found an error or want to contribute? Edit this page on GitHub.*
